DRC Encoder Part Number	Dynapar Crossover and Specifications
DRC 25D Encoder	HA25 Shafted Incremental Encoder, 2.5" Flange Size, 1 to 2540 PPR. View Data Sheet HR25 Shafted Incremental Encoder, 2.5" Flange Size, 1 to 1024 PPR. View Data Sheet HC25 Shafted Incremental Encoder, 2.5" Flange Size, 3000 to 5000 PPR. View Data Sheet
DRC A25 Encoder	AI25 Parallel Absolute Encoder, 2.5" Flange Size,10-14 Bit Single-turn, 12 Bit Multi-turn. View Data Sheet
DRC H25 Encoder	HA25 Shafted Incremental Encoder, 2.5" Flange Size, 1 to 2540 PPR. View Data Sheet HR25 Shafted Incremental Encoder, 2.5" Flange Size, 1 to 1024 PPR. View Data Sheet HC25 Shafted Incremental Encoder, 2.5" Flange Size, 3000 to 5000 PPR. View Data Sheet
DRC 150/152/153 Encoders	E14 Miniature Incremental Encoder, <2.0" Flange Size,100 to 2540 PPR. View Data Sheet
DRC H15 Encoder	E14 HS Miniature Incremental Encoder With Hubshaft and Tether, <2.0" Flange Size,100 to 2540 PPR. View Data Sheet
DRC HD2 Encoder	H20 Shafted Incremental Encoder, 2.0" Flange Size,1 to 2540 PPR. View Data Sheet
DRC H20 Encoder	HS20 Sealed Hollowshaft Encoder, 2.0" Flange Size,1 to 2540 PPR. View Data Sheet
DRC HS30 Encoder	HS35R Sealed Hollowshaft Encoder, 2.0" Flange Size,1 to 2540 PPR. View Data Sheet
DRC HS30 Encoder	HS35iQ Heavy Duty Hollowshaft Encoder with Fault Detection, Programmable Resolution up to 20000 PPR, 3.5" Flange Size. View Data Sheet
DRC H5, F21 Encoders	H20 Shafted Incremental Encoder, 2.0" Flange Size,1 to 2540 PPR. View Data Sheet H20HS Incremental Encoder With Hubshaft and Tether, 2.0" Flange Size,1 to 2540 PPR. View Data Sheet
DRC M21 Encoder	E23 Miniature Encoder Incremental, Optical Standard Size 23 (2.3" diameter),1 to 2540 PPR. View Data Sheet
DRC F21A Encoder	HC20 Incremental Encoder For Steppers and Small Servos,2.0" Flange Size,500 to 2500 PPR. View Data Sheet
DRC T23 Encoder	M53 Incremental Encoder,Easy Installation, For Steppers and Small Servos. View Data Sheet
DRC 730, 731, 830, 831 Encoders	M15 Incremental Encoder Modular Design, Easy Install For Steppers and Small Servos, <2.0" Flange Size, 200 to 1024 PPR. View Data Sheet
